Chipset: Intel Q570 Rozměrový formát: microATX (24.4cm x 24.4cm) Podpora pro procesory: *11th Gen Intel Core Processors & 10th Gen Intel Core, Pentium Gold and Celeron Processors *Supports Intel 14 nm CPU *Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 Patice procesoru: Intel Socket LGA1200 Pozice na paměti: 4 x DIMM Podpora pro paměti: *10th Gen Intel Core i7/i9 processors support 2933/2800/2666/2400/2133 natively, others will run at the maximum transfer rate of DDR4 2666MHz *11th Gen Intel processors support 2933/2800/2666/2400/2133 natively Maximální velikost operační paměti: 128 GB Podpora pro paměti typu: DDR4 *Dual Channel Memory Architecture *Supports Intel Extreme Memory Profile (XMP) *Optimem *3200(OC)/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory Grafické výstupy: *dle procesoru Zvuková karta: *Realtek ALC897 7.1 Surround Sound High Definition Audio CODEC* - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - Supports up to 24-Bit/192 kHz playback Síťová karta: *1 x Intel® 1Gb Ethernet Rozšiřující sloty: *1 x PCIe 4.0/3.0 x16 slot - Intel 11th processors support PCIe 4.0 x16 mode - Intel 10th processors support PCIe 3.0 x16 mode *2 x PCIe 3.0 x1 slots - Intel Q570 Chipset SATA: *6 x SATA 6Gb/s ports M.2: *2 x M.2 slots USB: *zadní USB porty ( celkem 6) - 4 x USB 3.2 Gen 2 ports (4 x Type-A) - 2 x USB 2.0 ports (2 x Type-A) *přední USB porty ( celkem 7) - 1 x USB 3.2 Gen 1 front panel connector (suppports USB Type-C) - 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports - 2 x USB 2.0 headers support additional 4 USB 2.0 ports Interní porty: *1 x 4-pin CPU Fan header *2 x 4-pin Chassis Fan headers *1 x 24-pin Main Power connector *1 x 8-pin +12V Power connector *2 x M.2 slots (Key M) *6 x SATA 6Gb/s ports *1 x USB 3.2 Gen 1 Front Panel connector (suppports USB Type-C) *1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports *2 x USB 2.0 headers support additional 4 USB 2.0 ports *1 x Clear CMOS header *1 x Chassis Intrude header *2 x COM Port headers *1 x Front Panel Audio header (AAFP) *1 x COM debug header *1 x DIS ME jumper *1 x LPT header *1 x Mono-out header(with Amp IC) *1 x M.2 slot (Key E) *1 x SMBUS header *1 x Speaker header *1 x 10-1 System Panel header Externí porty: *4 x USB 3.2 Gen 2 ports (4 x Type-A) *2x USB 2.0 ports (2 x Type-A) *2 x DisplayPort *1 x HDMITM *3 x Audio jacks *1 x Intel I219-LM 1Gb Ethernet *1 x PS/2 keyboard (purple) port *1 x PS/2 mouse (green) port BIOS: 128+64 Mb Flash ROM Stránka výrobce: https://www.asus.com/Motherboards-Components/Motherboards/Business/Pro-Q570M-C-CSM/techspec/
