Podrobnosti o produkte
Popis produktu:
MBD-X11SCH-F-B
Supermicro mainboard server X11SCH-F Single Socket H4 (LGA 1151), 8 SATA3 (6Gbps); RAID 0, 1, 5, 10; 2x 1GbE LAN with Intel I210-AT; 1 PCI-E 3.0 x8 (in x16) and 1 PCI-E 3.0 x8 slots, 4 DIMM slots, bulk
Technical Specification
Main Board Server - Processor
Chipset: Intel C246
CPU Socket Standard: Socket 1151
Supports Central Processor Unit: Intel Celeron
Intel Pentium
Intel Core i3
Intel Xeon E-2100 Series
Intel 8th Gen Processors
Intel 9th Gen Processors
Intel Xeon E-2200 Series
CPU Maximum Quantity Supports: 1
Features: Supports 14nm Processors
Main Board Server - Memory
Memory Type: DDR4 SDRAM
Provides Error Checking Method: ECC
Memory Speed: 2133MHz(PC4-17000)
2400MHz(PC4-19200)
2666MHz(PC4-21300)
Memory Form Factor: DIMM 288-pin
Maximum Installable System Memory Storage Capacity: 128 GB
Memory Slot Total Quantity: 4
Memory Features: Unbuffered
Controller
Integrated: Storage Controller:
Supports: Level 0, Level 1, Level 10, Level 5
SATA III-600 (8)
Storage Controller:
PCI Express 3.0 x4 (1 x M.2)
Main Board Server - Video Output
Video Controller Integrated: yes
Video Chipset: Aspeed AST2500
Main Board Server - Networking Specifications
LAN Architecture: Integrated: Gigabit Ethernet/Fast Ethernet/Ethernet (Intel i210)
Slot Provided
PCI Express 3.0 x8: 2
Interface Provided
USB 3.1 Gen 1: 1 (USB Type A)
USB 3.1 Gen 2: 2 (USB Type A)
USB 2.0: 2 (USB Type A)
VGA: 1 (15-pin DB)
LAN: 1 (RJ-45)
Serial: 1
Main Board Server - Mainboard Features
BIOS Type: UEFI
BIOS Features: PnP Support
USB Keyboard support
SMBIOS 2.7 Support
PCI 3.0
ACPI 6.0 Support
256 Mb Flash ROM
UEFI 2.7
Wake up/Sleep: RTC (real time clock) Wake up
Hardware Monitoring: Chassis Fan Tachometer
CPU Fan Tachometer
CPU Temperature
Chassis Temperature Sensing
Main Board Server - Environment
Maximum Operating Ambient Temperature: 50 °C
Minimum Operating Ambient Temperature: 0 °C
Maximum Operating Humidity: 90 %
Minimum Operating Humidity: 8 %
Main Board Server - Dimensions&Weight
Form Factor: Micro ATX
Height (mm): 243.8 mm
Width (mm): 243.8 mm
