ATEN 4-Port USB HDMI Multi-View KVMP™ Switch CM1284-AT-G





ATEN 4-Port USB HDMI Multi-View KVMP™ Switch CM1284-AT-G






ATEN 4-Port USB HDMI Multi-View KVMP™ Switch CM1284-AT-G




  • ATEN 4-Port USB HDMI Multi-View KVMP™ Switch CM1284-AT-G
  • ATEN 4-Port USB HDMI Multi-View KVMP™ Switch CM1284-AT-G
  • ATEN 4-Port USB HDMI Multi-View KVMP™ Switch CM1284-AT-G
















Výrobca

ATEN

KódITK537944
Part No.CM1284-AT-G
Dostupnosť po pobočkách
nie je skladom

NRE

nie je skladom

NR

nie je skladom

BA


DPH 20%
Vaša cena s DPH
4 938.50
bez DPH 4 115.42

Vaša cena bez DPH
Garancia cenyNašli ste inde na internete nižšiu cenu? Informujte nás!
Objednať
nie je skladom


Hodnotenie produktu
Hodnotené 3x
Záruka koncový zákazník: 2 Roky
Záruka firma: 2 Roky
Výrobca:

ATEN


Kód: ITK537944
Part No.: CM1284-AT-G


















4-Port USB HDMI Multi-View KVMP switch with Dual Display. One display is with Quad and PiP/PbP/PoP modes, and the other is with full-screen mode Easily resize and / or reposition any PiP or PbP to suit users’ viewing needs; Supports superior video qualit





  •

ATEN 4-Port USB HDMI Multi-View KVMP™ Switch CM1284-AT-G



Podrobnosti o produkte





Popis produktu:

4-Port USB HDMI Multi-View KVMP switch with Dual Display. One display is with Quad and PiP/PbP/PoP modes, and the other is with full-screen mode
Easily resize and / or reposition any PiP or PbP to suit users’ viewing needs; Supports superior video quality – up to 4K DCI @ 30Hz(4096 x 2160 @ 30Hz)
DCC (Daisy Chain Control) — Controls up to 3 additional CM1284 units from a single console; Cascade up to 2 levels — Controls up to 16 computers (with up to 4 x 4 Multi-view mode)
Boundless Switching – Simply moves the mouse cursor across windows to switch to other video sources

ATEN CM1284 4-Port USB HDMI Multi-View KVMP™ Switch improves the operational efficiency of real-time monitoring. The CM1284 allows users to manage the data more efficiently by allowing multiple sources to be selected, switched, and displayed at the same time with independent keyboard and mouse control.
Advanced video support provides a better-defined HDMI connection with video resolutions up to 4K (4096 x 2160 @ 30 Hz). The CM1284 guarantees users a real-time monitoring functionality by offering dual outputs on console side. One provides the following display modes: Quad View, Picture in Picture (PiP), Picture by Picture (PbP), Picture on Picture (PoP), and the other one provides Full Screen mode. Featuring Boundless Switching, the CM1284 allows users to simply move the mouse cursor across windows to switch to other video sources. This makes it easier to instantly access and control the target computer.

Incorporating Daisy Chain Control (DCC) capability, users are allowed to control up to 3 additional CM1284 units via a single console. In addition, CM1284 can be cascaded up to 2 levels to reach the maximum of 16 video sources to be simultaneously selected, switched, and displayed with independent keyboard and mouse control.

Engineered to meet the ever-increasing demand for multi-view functionality, the CM1284 is specifically designed for where real-time monitoring is needed such as aviation industry, financial trading, and medical application.

Features

Multi-view console controls up to four video sources on one screen with display modes including Quad View, Picture in Picture (PiP), Picture by Picture (PbP), and Picture on Picture (PoP)
Features dual output on console side – a multi-view output and a full screen output
Easily resizes and / or reposition any PiP or PbP to suit users’ viewing needs
System configuration via front panel, OSD, IR Remote, and RS-232 commands – display mode and port selection
Supports superior video quality – Up to 4K (4096 x 2160 @ 30 Hz)
Drop down menu – edit display windows and other functions with the mouse and on-screen control panel
Computer selection via front panel pushbutton and hotkey, mouse, and the serial commands*
Boundless Switching – Simply moves the mouse cursor across windows to switch to other video sources
Video DynaSync™ – exclusive ATEN technology eliminates boot-up display problems and optimizes the resolution when switching among different sources
EDID Expert™ – Selects optimum EDID settings for smooth power- up, high-quality display and use of the best video resolution across different screens
DCC (Daisy Chain Control) – Controls up to 3 additional CM1284 units from a single console
Cascade up to 2 levels – Controls up to 16 computers (with up to 4 x 4 Multi-view mode)
HDCP 1.4 compliant
Console keyboard emulation / bypass feature that support most multimedia keyboards
Console mouse port emulation / bypass feature that supports most mouse drivers and multifunction mice
Independent switching for USB peripheral port, audio function and KVM switch focus
Power on detection
Auto Scan feature
Firmware upgradable via computer’s USB port
Full bass response provides a rich experience for 2.1 channel audio
Multilingual keyboard mapping – supports English, French, Japanese, and German keyboards
Hot-pluggable
Supports keyboard combinations via emulation (for Sun / Mac)**

Note:
*Mouse port switching is only workable under mouse emulation mode and is for 3-key USB wheel mouse only
**PC keyboard combinations emulate Mac keyboard. Mac keyboard only work with their own computers

Package Contents
1x CM1284 4-Port USB HDMI Multi-View KVMPTM Switch
4x USB HDMI Cables
1x Power Cord
1x IR Remote Control
1x Rack Mount Kit
1x User Instructions
