Popis produktu:

Incorporates 48 RJ-45 10/100/1000 Mbps ports and 4 SFP uplink ports (10Gbps)
Automatically detects KE/VE89 series devices
Plug-and-play without additional settings
High-performance Gigabit Ethernet L2 access switch with 176 Gbps switching capacity

The ES0152 is a feature-rich managed switch for ATEN KE series KVM over IP extenders and VE89 series Video over IP extenders. Ideal for installation in combination with the KE / VE89 series products, the ES0152 helps users build their OT infrastructure with the KE series by eliminating the hassles of complicated setup.
Deploying the ES0152 is fast and easy. With everything plug and play, there is no need to install software or configure devices. Simply connect the KE / VE89 transmitters and receivers to the ES0152 using Cat 5e/6 cables and all KE / VE89 series devices on the same LAN will automatically be detected.

The ES0152 network switch provides a 52-port, high-performance configuration, a complete array of L2 features and advanced functionalities including Layer 3 static route, DHCP server, IPv6 support and LLDP, delivering a versatile solution for improving network performance.

The ES0152 offers a combination of SFP+ (fiber) and RJ45 (copper) ports for servicing a range of network needs. It delivers 4 (1G/10G) SFP+ and 48 (10M/100M/1G) RJ45 ports.

The ES0152 comes with embedded DMS functions to facilitate device management anytime and anywhere. Its intuitive, user-friendly interface enables IT administrators to set up and manage their networks and all the connected KE / VE89 devices effortlessly. It also has comprehensive security features such as IP source guard and ACL to guard your network from unauthorized access.

With a full range of functions to help with optimizing network efficiency, manageability and reliability for their network environment, the ES0152 is an ideal network switch solution for SMBs and enterprises, and even more so for those that have chosen to adopt ATEN KE series KVM over IP extenders or VE89 series Video over IP extenders into their OT infrastructure.

Auto detects KE/VE89 series devices
Plug-and-play without additional settings
Supports IGMP Snooping Fast Leave
Supports Flow Control
Supports IGMP v1/v2/v3 Snooping and IGMP v1/v2 Querier
Supports 48 Gigabit Ethernet ports and 4 SFP uplink ports (10Gbps)
High-performance Gigabit Ethernet L2 access switch with 176 Gbps switching capacity - significantly improve the responsiveness of applications and file transfer times
Built in Device Management System (DMS) to provide an overview of all connected KE/VE89 devices for management
Supports IEEE 802.1w Rapid Spanning Tree Protocol – ensuring a faster recovery from failed links and enhancing overall network stability and reliability
Comprehensive QoS – allowing the marking, classification, and scheduling of up to four traffic types across the network
Enhanced Security - Port Security limits the total number of devices using a switch port and protects against MAC flooding attacks
IPv4/IPv6 Management

Package Contents
1x ES0152 52-Port GbE Managed Switch
1x LIN2-418K-E12G AC Power Cord
1x RJ45 to DB9 Serial Console Cable
1x Foot Pad Set (4 pcs.)
1x Mounting Kit
1x User Instructions

Connectors

RJ-45 10/100/1000 Ports
48
SFP Uplink Ports
4
Console Ports
1 x RJ45

Performance
Switching Capacity
176 Gbps
Forwarding Rate
130.95 Mpps
Jumbo Frames
10240 Bytes

Maximum Input Power Rating
100-240V AC,50-60Hz

Power Consumption
AC110V/45.98W;AC220V/46.55W

Environmental
Operating Temperature
0–50°C
Storage Temperature
-20–60°C
Humidity
10–90% RH, Non-condensing

Physical Properties
Rack Space
19"
Housing
Metal
Weight
4.20 kg ( 9.25 lb )
Dimensions (L x W x H)
44.20 x 30.00 x 4.40 cm
(17.4 x 11.81 x 1.73 in.)
Carton Lot
2 pcs

Note
For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
