Popis produktu:

Výhody
Podpora procesorov AMD Socket FM2+ Athlon™/A-Series
Čipset AMD AMD A68H
Podpora 2-DIMM DDR3-2600(OC) až do maximálnej kapacity 32G
Podpora USB 3.2
Podpora HDMI
Podpora GbE LAN
Technológia AMD Dual Graphics

CPU SUPPORT
AMD FM2+ A-series APU Maximum CPU TDP (Thermal Design Power) : 100Watt * Please refer to www.biostar.com.tw for CPU support list.

MEMORY
Support Dual Channel DDR3 800/ 1066/ 1333/ 1600/ 1866/ 2133/ 2400(OC)/ 2600(OC) MHz 2 x DDR3 DIMM Memory Slot Max. Supports up to 32GB Memory *Please refer to www.biostar.com.tw for Memory support list.

INTEGRATED VIDEO
By CPU model
Supports DX12
Supports HDCP
AMD Dual Graphics Technology

STORAGE
4 x SATA III Connectors (6Gb/s) : Supports AHCI & RAID 0, 1, 10

LAN
Realtek RTL8111H - 10/100/1000Mb/s Controller

AUDIO CODEC
Realtek ALC662 6-Channel HD Audio

USB
2 x USB 3.2 Gen1 Port (5Gb/s) (2 on rear I/Os)
6 x USB 2.0 Port(2 on rear I/Os and 4 via internal
headers)

EXPANSION SLOT
1 x PCI-E 3.0 x16 Slot
1 x PCI-E 2.0 x1 Slot

REAR I/O
1 x PS/2 Mouse
1 x PS/2 Keyboard
2 x USB 3.2 Gen1 (5Gb/s) Port
2 x USB 2.0 Port
1 x HDMI Connector
1 x VGA Port
1 x LAN Port
3 x Audio Jacks

INTERNAL I/O
2 x USB 2.0 Header(each header supports 2 USB 2.0 ports)
4 x SATA III Connector (6Gb/s)
1 x Front Audio Header
1 x Front Panel Header
1 x CPU Fan Connector
1 x System Fan Connector
1 x 4-Pin Power Connector
1 x 24-Pin Power Connector
1 x Clear CMOS Header

H/W MONITORING
CPU / System Temperature Monitoring
CPU / System Fan Monitoring
Smart / Manual CPU Fan Control
CPU/DDR Voltage Monitoring

DIMENSION
Micro ATX Form Factor Dimension: 21.5 cm x 17 cm ( W x L )

OS SUPPORT
SSupports Windows XP/ 7/ 8/ 8.1(64bit)/ 10(64bit) *Biostar reserves the right to add or remove support for any OS with or without notice.

BUNDLE SOFTWARE
BullGuard

ACCESSORIES
2 x SATA Cable
1 x I/O Shield
1 x DVD Driver
1 x User Manual
