Popis produktu:

Industrial Power Supply 48V DC, 120W AC-DC, metal case, DIN rail mountale

Description
Industrial Power Supply 48V DC, 120W AC-DC, metal case, DIN rail mountable

Compact size and wide temperature range

Wide range AC input between 90V AC ~ 264V AC
DIN rail TS-35/7.5 or TS-35/15 support
48V DC output voltage
120W output wattage
DIGITUS® economical slim DIN rail power supply series adapt to be installed on TS-35/7.5 or TS-35/15 mounting rails. The series adopts wide range AC input beween 90V AC to 264V AC and is design with metal housing, enhancing the unit´s power dissipation. DIN rail power suply series offer a working efficiency of 88% and can operate between -20°C ~ 60°C. It is equipped with over-load , short-circuit, over-voltage and over-temperature protection, which makes it a competitive power supply solution for industrial applications.

Technical Details
48V DC output voltage
2.5A rated output current
0 ~ 2.5A current output range
120W rated output power
120mVp-p ripple and noise
48V ~ 55V output voltage adj. range
± 1.0% output voltage tolerance
± 0.5% line regulation
±1.0% load regulation
1200ms, 60ms/230VAC setup, rise time
16ms/230VAC hold up time
90 ~ 264VAC input voltage range
47 ~ 63Hz input frequenzy range
88% typical efficiency
1.3A/230VAC typical input AC current
35A/230VAC inrush current
<1mA/240VAC leakage current
105 ~ 130% rated output power overload protection
56 ~ 65V over voltage protection
over temperature protection
±0.03%/°C temperature coefficient
Working temperature: -20 ~ +60°C
Working hunidity: 20 ~ 95% RH
Storage temperature: -40 ~ +85°C
Package content
Industrial Power Supply
QIG (quick installation guide)
