Popis produktu:

MOTHERBOARD
Form factor Mini ITX, µATX, ATX, eATX, SSI EEB
max. Motherboard size 305mm x 345mm (12" x 13.5")
INSTALLATION DIMENSIONS
Height CPU cooler (max.) 155mm
Length graphics card (max.) 345mm
DRIVE BAYS
5.25" external 2xą
5.25" external (slim)
3.5" or 2.5" external (Hot-Swap) 16x
3.5" internal 2xą
2.5" internal 8xą
FRONT CONNECTORS
USB 3.0 1x
USB 2.0 1x
POWER SUPPLY
PS2/mini redundant PSU
ATX PSU
FAN MOUNTING OPTION
Front 4x 40mm (optional)
Inside 3x 120mm (serial, Molex connector, hot pluggable)
Rear 2x 80mm (serial, Molex connector)
CONTROLS & LED
Controls Power-Switch
Reset-Button
LED Power
HDD Activity
3x Network Activity
Alert
OTHER DATA
S-ATA/SAS-Backplane + SFF-8087 (max. 12Gbit/s)
Dimensions (h/w/d) 178 x 481 x 688mm
Material 1.0-1.2mm Steel
Warranty 24 months
SCOPE OF DELIVERY & FEATURES
Scope of delivery
Case

Retail packaging

Screw set

Mounting bracket for ATX (preassembled), 4HU redundant and 3HU triple redundant PSU

Adapter for 2HU PSU + optional 80mm fan bracket

Mounting bracket for diverse PSU

Assembly tool

Features
2x 80mm fan and 3x 120mm fan included (3x 120mm fan hot pluggable)

Drive brackets removable

USB 3.0 and USB 2.0 as block connector

4x Hot-Swap backplanes with one SFF-8087 socket each    Important Note!

LOGISTICAL DATA
Shipping Unit 1 Pcs
EU palett 14 Pcs
Weight net = 15.14kgs
gross = 17.73kgs
Item number 88887120
EAN-Code 4260133126411
