Popis produktu:

GENERAL
Chipset Type Intel 865PE / Intel ICH5
Compatible Processors Pentium 4, Celeron D
Processor Socket LGA775 Socket
Max Bus Speed 800 MHz
Max Processors Qty 1
ManufacturerFoxconn
EXPANSION / CONNECTIVITY
Expansion Slots 2 x DIMM 184-pin (2.5 V)
1 x AGP 8x
3 x PCI
1 x CPU
Internal Interfaces 1 x floppy
Additional Connectors (Optional) 1 x IEEE 1394 (FireWire), 4 x USB 2.0
STORAGE CONTROLLER
Interface Type Serial ATA-150
PROCESSOR
Max Supported Qty 1
Installed Qty 0
INTERFACE PROVIDED
Type storage
Interface ATA-100, Serial ATA-150
Qty 1, 2, 4
Connector Type 40 pin IDC, 7 pin Serial ATA
Type FireWire, LAN, PS/2 keyboard, PS/2 mouse, USB 2.0, audio line-in, audio line-out, microphone, parallel, serial
Connector Type mini-jack
CACHE MEMORY
Type none
MISCELLANEOUS
Product Type motherboard
NETWORKING
Data Link Protocol Ethernet, Fast Ethernet
Network Ethernet
AUDIO
Compliant Standards AC '97
PROCESSOR / MEMORY / STORAGE
Max Supported Qty 1
AUDIO OUTPUT
Sound Output Mode 5.1 channel surround
Compliant Standards AC '97
Type sound card
Audio 6-channel
VIDEO
Video Output none
RAM
Max Supported Size 2 GB
Features dual channel memory architecture
LAN
Network Interfaces Ethernet
SUPPORTED RAM
Bus Clock 400 MHz, 333 MHz, 266 MHz
Registered or Buffered Unbuffered
Features Dual channel memory architecture
Speed PC3200, PC2700, PC2100
Technology DDR
Max Size 2 GB
HEADER
Brand Foxconn
Product Line Foxconn
Model 865PE7MC-ES
Packaged Quantity 1
Compatibility PC
MAINBOARD
Form Factor micro ATX
Processor Socket LGA775 Socket
Compatible Processors Celeron D, Pentium 4
Data Bus Speed 800 MHz
Chipset Type Intel 865PE
I/O Controller Intel ICH5
Supported RAM Technology DDR SDRAM
Supported RAM Speed 266 MHz, 333 MHz, 400 MHz
Supported RAM Standard PC2100, PC2700, PC3200
Supported RAM (Registered or Buffered) unbuffered
MAINBOARD FEATURES
Sleep / Wake Up suspend to RAM (STR), wake on LAN (WOL)
INTERFACES
Storage ATA-100, Serial ATA-150
USB 3.0 / FireWire FireWire
EXPANSION SLOTS
Total Qty 1, 2, 3
Voltage 2.5 V
Type AGP 8x, CPU, DIMM 184-pin, PCI
CABLE DETAILS
Type IDE cable, Serial ATA cable, floppy cable
Included Qty 1
SOFTWARE
Software Included drivers & utilities
DIMENSIONS & WEIGHT
Width 9.6 in
Depth 9.6 in
INTERNAL INTERFACES
Type floppy
Qty 1
FEATURES
Sleep / Wake Up Suspend to RAM (STR), wake on LAN (WOL)
GENERAL
ManufacturerFoxconn
