Chipset: Intel H510 Chipset Rozměrový formát: mATX Form Factor Podpora pro procesory: Supports 10th Gen Intel Core Processors, 11th Gen Intel Core Processors, Pentium Gold and Celeron Processors Patice procesoru: L1200 Pozice na paměti: 2x DDR4 memory slots Podpora pro paměti: *Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel CPU (by JEDEC & POR) *Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen Intel CPU (by JEDEC & POR) Max.velikost operační paměti: 64 GB Podpora pro paměti: *Supports Dual-Channel mode *Supports non-ECC, un-buffered memory *Supports Intel Extreme Memory Profile (XMP) Grafická karta: *1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz *1x VGA port, supports a maximum resolution of 2048x1536 60Hz, 1920x1200 60Hz Zvuková karta: *Realtek ALC897 Codec Síťová karta: *1x Intel I219V 1Gbps LAN controller Rozšiřující sloty: *1x PCIe x16 slot (From CPU) - Support up to PCIe 4.0 for 11th Gen Intel CPU, Support up to PCIe 3.0 for 10th Gen Intel CPU *1x PCIe 3.0 x1 slot (From PCH) *1x M.2 slot with E key for WiFi (PCIe) module only(M2_2) RAID řadič: ne SATA: *4x SATA 6Gb/s ports M.2: *1x M.2 slot USB: *zadní USB porty ( celkem 6 ) *2x USB 3.2 Gen 1 5Gbps ports *4x USB 2.0 ports *přední USB porty ( celkem 4 ) *2x USB 3.2 Gen 1 5Gbps ports *2x USB 2.0 ports Interní porty: *1x 24-pin ATX main power connector *1x 8-pin ATX 12V power connector *4x SATA 6Gb/s connectors *1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports) *1x USB 2.0 connector (supports additional 2 USB 2.0 ports) *1x 4-pin CPU fan connector *1x 4-pin system fan connector *1x Front panel audio connector *2x System panel connectors *1x Serial port connector *1x Chassis Intrusion connector *1x Clear CMOS jumper *1x TPM module connector Externí porty: *1x HDMI *1x VGA *1x Mouse / Keyboard connector *1x LAN port *Audio connector *4x USB 2.0 *2x USB 3.2 Gen 1 5Gbps Type-A Stránka výrobce: https://www.msi.com/Motherboard/H510M-A-PRO/Specification
