Popis produktu:

RoHS compliant products


CompactFlash Specification Version 6.0 Complaint


Support S.M.A.R.T (Self-defined)


Support Security Command


Support Static Data Refresh, Early Retirement to extend product life


Operation Modes: PC Card Memory, PC Card IO, True IDE


True IDE Mode supports: UDMA0-5, MDMA0-2, PIO0-6


True IDE mode: Fixed Disk (Standard)


PC Card Mode supports up to Ultra DMA Mode 5


PC Card Mode: Removable Disk (Standard)


Built-in BCH ECC (Error Correction Code) functionality and global wear-leveling algorithm ensures highly reliable of data transfer


Advanced power design, the product can protect itself when abnormal power occurs or irregular temperature usage.


Interface(connector)
  Compact Flash, 50P

Form Factor
  Compact Flash Card

Flash Type
  MLC

Capacity(GB)
  8GB/ 16GB/ 32GB/ 64GB

Max. R/W Performance(MB/s)(Vary by density)
  Read: 90MB/s, Write: 60MB/s

Op. Voltage(V)
  3.3V±5% or 5V±10%

Power Consumption(W)
  0.76W

Op. Temp.(?)
  -25?~85?

Storage Temp.(?)
  -40?~85?

Humidity(%)
  0%~95%

Shock(G)
  1500G, 0.5ms, 3 axis

Vibration(Hz/G)
  20G (Peak-to-Peak), 20Hz to 2000Hz(Frequency)

Dimensions(mm)
  42.8mm × 36.4mm × 3.3mm

MTBF(hours)
  1,000,000 hours
